Samtec ExaMAX® High-Speed Backplane System: Featured Product Summary

Samtec ExaMAX® High-Speed Backplane System: Featured Product Summary

Components on wall image; Samtec's high-speed backplane system receives a highlight article here on Sourcengine.

ExaMAX® high-speed backplane interconnects deliver 56 Gbps electrical performance.

The ExaMAX® contact system achieves two reliable points of contact at all times and minimizes residual stub for improved signal integrity performance, while providing low mating force and excellent contact normal force. Signal wafers incorporate a one-piece, embossed ground structure which improves crosstalk performance.

Traditional backplane and direct-mate orthogonal available with backplane cable and coplanar versions in development.

FEATURES:

56 G

  • Enables 56 Gbps electrical performance on 2.00 mm column pitch
  • Meets industry specifications such as PCI Express®, Intel OPI and UPI, SAS, SATA, Fibre Channel, Infini Band™ and Ethernet
  • Meets and exceeds OIF CEI-28G-LR specification for 28 Gbps standards
  • Direct-mate orthogonal eliminates the need for a backplane/midplane and shortens the signal path for improved signal integrity
  • Allows designers to optimize density or minimize board layer count
  • Samtec Teraspeed Consulting: Experts in design, optimization, and evaluation of high-speed backplane systems
  • Offerings: Traditional Backplane, Backplane Cable, Direct-mate Orthogonal, Coplanar
Samtec examax series connectors
Figure 1 - Originally posted on Samtec's website

ExaMAX® Series:

1. EBTM – Shop Here

ExaMAX® 2.00 mm Vertical Header Assembly
Features:
  • 4 or 6 pairs per column
  • 2.00 mm (.0787") pitch
  • Press fit termination

Data Sheet: Download Here

2. EBTM-RA

ExaMAX® 2.00 mm Right Angle Header Assembly
Features:
  • 4 or 6 pairs per column
  • 2.00 mm (.0787") pitch
  • Press fit termination
  • Right-angle orientation

Data Sheet: Download Here

3. EBTF-RA – Shop Here

ExaMAX® 2.00 mm Right-Angle Receptacle
Features:
  • 4 or 6 pairs per column
  • 2.00 mm (.0787") pitch
  • Press fit termination

Data Sheet: Download Here



4. EBDM-RA

ExaMAX® 2.00 mm Direct Mate Orthogonal Header
Features:
  • Eliminates the mid-plane improving airflow and requiring fewer connectors
  • 2.00 mm (.0787") pitch
  • 6 pairs per column
  • Shorter signal path for improved signal integrity performance
  • Integral guide post

Data Sheet: Download Here

5. EBCM

ExaMAX® Backplane Cable Header
Features:
  • Intermateable with all ExaMAX® connectors
  • Samtec’s Eye Speed®ultra low skew twinax cable provides increased flexibility and routability
  • Improves signal integrity and     increases signal path length at higher data rates

Data Sheet: Download Here



6. EBCF

ExaMAX® Backplane Cable Socket
Features:
  • Improves signal integrity and increases signal path length at higher data rates
  • Intermateable with all ExaMAX® connectors
  • Samtec’s Eye Speed® ultra-low skew twinax cable provides increased flexibility and routability

Data Sheet: Download Here

7. EGBM

ExaMAX® Terminal Guide Module
Features:
  • Vertical or right-angle orientation
  • Guide module for EBTF-RA and EBTM Series

Data Sheet: Download Here

8. EGBF

ExaMAX® Socket Guide Module
Features:
  • Right-angle orientation
  • Guide module for EBTF-RA and EBTM Series

Data Sheet: Download Here

9. EPTT – Shop Here

ExaMAX® Terminal Power Module
Features:
  • Right-angle orientation
  • Power module for EBTF-RA and EBTM Series

Data Sheet: Download Here

10. EPTS – Shop Here

ExaMAX® Socket Power Module
Features:
  • Vertical or right-angle orientation
  • Power module for EBTF-RA and EBTM Series

Data Sheet: Download Here

11. EBCL

Vertical Latching Shroud for ExaMAX® Backplane Cable Socket
Features:
  • Provides retention for EBCF-VT to EBTM-VT
  • Surrounds and protects EBTM-VT
  • Screw mounts secure the EBCL to the board (M2 thread)

Data Sheet: Download Here

12. EBCB

Panel Retention Bracket for ExaMAX® Backplane Cable Header
Features:
  • Provides retention for EBCM through a backplane
  • Screw mounts secure the EBCB to the backplane

Data Sheet: Download Here
