Jauch Lithium Coin Cell and Manganese Dioxide Batteries – Technical Summary

Lithium batteries come in a variety of versions which contrast in terms of separator, electrolyte and cathode. Considering they are applicable to a broad spectrum of applications and industries, they come indifferent designs and sizes. As the result of their high voltage (3 volts),high temperature range, high capacity and long-life cycle due to low discharge,they are one of the most commonly used batteries across numerous industries.

Most commonly, Jauch’s lithium coin cell batteries can be found in watches, toys, car keys, digital weight scales, medical equipment and tools, as well as memory any type of memory back up.

On the technical side, lithium is an ideal negative electrode material. As such, it has the highest possible voltage. Therefore,this type, lithium manganese dioxide batteries (LiMnO2), of batteries are used across so many applications including electronic components and battery back-up for motherboards.

Below, we will discuss the technical capabilities of the commonly used Jauch batteries.

CR1220

With a wide assortment of mounting options including through hole, surface mount and wire terminals, CR1220 provides a reliable energy for a design application.

CR1220 Battery from Jauch

Product specifications:

·        Nominal Voltage: 3V

·        Jauch part number: 246534

·        Nominal Capacity: 40 mAh

·        Standard Load: 62 kΩ

·        Standard Current: < 0.1 mA

·        Max. Continuous Current: < 1.0 mA

·        Max. Pulse Current: 4 mA

·        Operating Temperature: -30 C° to + 70 C°

·        Weight Approx.: 0.75 gr.

·        Chemistry: Li/MnO2

·        UI1642: MH62838

Dimensions for CR1220 battery from Jauch
Graph Characteristics for CR1220 battery from Jauch

Buy Now on Sourcengine

CR2032

Lithium button and coin cell batteries, such as the CR2032, are used to power small portable electronics devices such as wrist watches,pocket calculators, artificial cardiac pacemakers, implantable cardiac defibrillators, automobile key less entry transmitters, and hearing aids.Button and coin cell batteries are typically 5-25 millimeters in diameter and 1-6 millimeters in height. Lithium sizes can be determined from their reference numbers. The first two digits refer to the diameter of the battery in mm and the second two digits give the height or thickness of the battery in tenths of mm. So, for example, a CR2032 is a Lithium button cell which is 20 mm in diameter and 3.2 mm thick. A CR2430 is a lithium battery, 24 mm in diameter and 3.0 mm thick. Lithium button and coin cell batteries have a BR or CR prefix and primarily provides 3 volts.

CR2032 battery from Jauch

Specifications:

·        Nominal Voltage: 3V

·        Jauch part number: 245785

·        Nominal Capacity: 240 mAh

·        Standard Load: 15 kΩ

·        Standard Current: 0.2 mA Max.

·        Continuous Current: 3 mA Max.

·        Pulse Current: 15 mA

·        Operating Temperature: -30 C° to + 70 C°

·        Weight Approx.: 2.9 gr.

·        Chemistry: Li/MnO2

·        UI1642: MH62838

Dimensions for CR2032 battery from Jauch
Graph characteristics for CR2032 battery from Jauch

Buy Now on Sourcengine

CR1620

CR1620 battery from Jauch

Specifications:

·        Nominal Voltage: 3V

·        Jauch part number: 245989

·        Nominal Capacity: 75 mAh

·        Standard Load: 47 kΩ

·        Standard Curent: 0.65 mA

·        Max. Continuous Current: 0.65 mA

·        Max. Pulse Current: 8 mA

·        Operating Temperature: -30 C° to +70 C°

·        Weight Approx.: 1.25 gr.

·        Chemistry: Li/MnO2

·        UI1642: MH62838

Buy Now on Sourcengine

CR1632

CR1632 battery from Jauch

Specifications:

·        Nominal Voltage: 3V

·        Jauch part number: 246535

·        Nominal Capacity: 135 mAh

·        Standard Load: 30 kΩ

·        Standard Current: 0.02 mA Max.

·        Continuous Current: 1 mA Max.

·        Pulse Current: 8 mA

·        Operating Temperature: -30 C° to +70 C°

·        Weight Approx.: 1.8 gr.

·        Chemistry: Li/MnO2

·        UI1642: MH62838

Dimensions for CR1632 battery from Jauch
Other Characteristics for CR1632 battery from Jauch

Buy Now on Sourcengine

CR123A

CR123A battery from Jauch

Specifications:

·        Nominal Voltage: 3V

·        Jauch part number: 245719

·        Nominal Capacity: 1500 mAh

·        Continuous Standard Load: 20 mA

·        Constant Discharge: 10 mA to 2V Max.

·        Continuous Discharge: 1000 mA Max.

·        Pulse Current: 3000 mA

·        Operating Temperature: -40 C° to +70 C°

·        Weight Approx.: 16.5 gr.

·        Chemistry: Li/MnO2

·        UI1642: MH62838

Applications:

  • Memory backup
  • Medical devices
  • Cameras
  • Remote sensors
  • Metering
Dimensions for CR123A battery from Jauch
Other characteristics for CR123A battery from Jauch

Buy Now on Sourcengine

CR2

CR2 batteries are commonly used in digital and film cameras.This type of battery can also be seen in flashlights and electronic devices.

CR2 battery from Jauch

Specifications:

·        Nominal Voltage: 3V

·        Jauch part number: 245718

·        Nominal Capacity: 900 mAh

·        Continuous Standard Load: 10 mA

·        Constant Discharge: 10 mA to 2V

·        Max. Continuous Discharge: 850 mA Max.

·        Pulse Current: 1500 mA

·        Operating Temperature: -40 C° to +70 C°

·        Weight Approx. 11.0 gr.

·        Chemistry: Li/MnO2

·        UI1642: MH62838

Buy Now on Sourcengine

Sourcengine is a leading marketplace for electronic components. We offer Jauch batteries at the most competitive prices and fast shipping. To find out more about Sourcengine and search for more electronic components, click here.
