Compliance Details

  • SB Code
    8541.10.00.70
  • HTS Code
    8541.10.00.70
  • ECCN Governance
    EAR
  • ECCN
    EAR99
Negotiated savings, bought with a click.
Quantity *
Target Price
Packaging type
Packaging condition
Date Code
Additional Information

3 traceable suppliers for BAV99S,115 available

3 traceable suppliers available

  • Includes:
  • Scheduled shipping up to a year
  • 3 year warranty
Supply Attributes
Supplier Availability Price Quantity Total
  • Date Code
  • Packaging
    Tape & reel
  • Pack Condition
    Full factory pack
  • Supplier Type
    Franchised distributor
  • Stock
    183,000
  • Delivery Date
    AUG 2, 2021
  • 3,000+
    $ 0.10579
Quantity
Increments of 3000
$ 0.00
  • Date Code
  • Packaging
    Tape & reel
  • Pack Condition
    Full factory pack
  • Supplier Type
    Franchised distributor
  • Stock
    948,000
  • Delivery Date
    AUG 2, 2021
  • 3,000+
    $ 0.10618
Quantity
Increments of 3000
$ 0.00
  • Date Code
  • Packaging
    Unknown
  • Pack Condition
    Unknown
  • Supplier Type
    Franchised distributor
  • Stock
    2,820
  • Delivery Date
    AUG 4, 2021
  • 2,533+
    $ 0.11252
Quantity
Increments of 1
$ 0.00

Technical Details

back to top
  • Diode Type
    RECTIFIER DIODE
  • JESD-30 Code
    R-PDSO-G6
  • Configuration
    2 BANKS, SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
  • JESD-609 Code
    e3
  • Package Shape
    RECTANGULAR
  • Package Style
    SMALL OUTLINE Meter
  • Surface Mount
    YES
  • Terminal Form
    GULL WING
  • Terminal Finish
    Tin (Sn)
  • Terminal Position
    DUAL
  • Number of Elements
    4
  • Output Current-Max
    0.2 A
  • Reference Standard
    AEC-Q101; IEC-60134
  • Number of Terminals
    6
  • Package Body Material
    PLASTIC/EPOXY
  • Power Dissipation-Max
    0.25 W
  • Diode Element Material
    SILICON
  • Operating Temperature-Max
    150 Cel
  • Operating Temperature-Min
    -65 Cel
  • Reverse Recovery Time-Max
    0.004 us
  • Moisture Sensitivity Level
    1
  • Rep Pk Reverse Voltage-Max
    100 V
  • Peak Reflow Temperature (Cel)
    NOT SPECIFIED
  • Time@Peak Reflow Temperature-Max (s)
    NOT SPECIFIED
